Migrating Legacy Maintain Procedures to Maintain Data

Maintain Data has a license code on the Reporting Server. If Maintain Data is not licensed, each Maintain Data page contains a diagonal watermark background image that says "Maintain Data Trial" to indicate that the product is not licensed.

An object in Maintain Data or JavaScript code is no longer referenced using Form.Objectname. All migrated variables are changed to Form_Objectname.

All Maintain code in the application event section is migrated into the application. A case is created for each event, and a task is assigned to that case. Display the Tasks & Animations panel. When you click on a control, you can see the task assigned to each case.

If the event contains JavaScript, you can view the JavaScript by clicking the Embedded JavaScript tab at the bottom of the form. To see if an object is associated with a JavaScript event, click the object and display the Properties panel. Click the lightning bolt to display the events. Clicking on an event name brings you to the code in the Embedded JavaScript view.

There are no longer Winform Set commands in Maintain Data. All of these commands are replaced by computed variables. Assign these variables to an object property and when the variable is evaluated, the property is set. Instead of the following Maintain command to make something invisible:

Winform Set Form.Object.Visible to No;

In Maintain Data, you use a Compute command, and assign that to the visible property of the object. For example:

Compute Var/a10 = 'Hidden';

You can assign variables by dragging them from the Requests & Data Sources panel directly onto the Properties panel of the object.

The Winform Get command is no longer supported. You can test the associated variable to get the current value.

The SetLayer command in Maintain has been replaced by the IbComposer_showLayer command in Maintain Data. The IbComposer_showLayer command allows layers to be set as visible or invisible at run time. It is used in a JavaScript event.

IWCTrigger code is no longer used for a JavaScript event to perform a Maintain case. Instead, a new task is created to perform the Maintain case and assigned to a Trigger Type of TBD. You can then drag that task into the JavaScript code and create:

IbComposer_triggerExecution("taskn",1);

This conversion is done for you at migration. If the IWCTrigger code was in a linked or embedded JavaScript file, you will have to perform this code conversion yourself.

When embedding HTML objects in HTMLTables, GetHTMLField was used to retrieve the selected or entered value at run time. You can now assign a Selection To field when creating the HTMLTable, making this unnecessary.

Retrieving the clicked row, column, or value from an HTMLTable has changed for using both Maintain Data and JavaScript code.

The Developer Studio functions ClickColumn, ClickRow, and Value(cell value) are now IbComposer_getClickedColumn, IbComposer_getClickedRow, and IbComposer_getClickedCellValue.

The following Developer Studio Maintain code is removed.

compute X/13 = Form1.HTMLTable1.Clickrow;
compute Y/13 = Form1.HTMLTable1.Clickcolumn;
compute Z/13 = Form1.HTMLTable1.value;

X and Y are still created, but are assigned in the HTMLTable Settings panel to the ClickRow and ClickColumn parameters.

The statement: Form1.HTMLTable1.value; is no longer supported and will have to be replaced. You can use the code:

compute Z/A10 = Stack(x).field;

where:

Stack

Is the name of the stack populating the HTMLTable.

x

Is the variable containing the ClickRow value.

field

Is the name of the field on which you are clicking.

This Developer Studio JavaScript code:

var col = Form1.HTMLTable1_ClickColumn.value;
var row = Form1.HTMLTable1_ClickRow.value;
var val = Form1.HTMLTable1_Value.value;

is replaced by:

var col = IbComposer_getClickedColumn(ctrl);
var row = IbComposer_getClickedRow(ctrl);
var val = IbComposer_getClickedCellValue(ctrl);

In Maintain, the command: Form1.HTMLTable1.RealBodyRowHeight = n was used to change the height of a row in an HTMLTable. In Maintain Data, this is done in the HTMLTable Properties panel.

Since the Maintain Data application is now part of an HTMLPage, the command self.Winexit or formname.Winexit is no longer supported.

The JavaScript onclick window.close function only works with Internet Explorer 11.

To see the JavaScript or CSS files that are associated with your migrated application, click the form and display the Settings panel. The names of your resource files can be found there.

When you expand the Forms folder on the tree, all application forms are displayed. You can display one or multiple forms by checking the box next to their names.

Databases are displayed once for all the requests. They are not displayed for each request.

• Two additional values for contentTypes were added to the ColumnSetContentType function. The two values are 3 - CheckBox and 4 - Select.
• The CellSetFont function has been enhanced to include additional styling information, as follows:

  grid1.CellSetFont(3,2,"italic bold 12px antique, serif");

• The syntax for the SetTopRow function is now:

  $('#Form1_Grid1_table').setTopRow

• The syntax of the functions no longer includes the form name.
• The Grid and JSGrid OnRowSized and OnRowSizing events are not available in App Studio.

During the migration process, the TextOnLeft property does not migrate. If you require this property in App Studio, set the Direction of text property in the Properties panel.
